Key specs
Input voltage85 ~ 264 V
Output voltage28 V
Output current26.8 AMax
Power1.2 kWMax
Outputs2
| Power | |
|---|---|
| Current - Output 1 | 26.8 A |
| Current - Output 2 | 26.8 A |
| Power (Watts) | 1200W |
| Voltage - Input | 85 ~ 264 VAC, 120 ~ 300 VDC |
| Voltage - Output 1 | 28V |
| Voltage - Output 2 | 28V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Size / Dimension | 11.00" L x 8.00" W x 2.50" H (279.4mm x 203.2mm x 63.5mm) |
| Other | |
| Applications | ITE (Commercial), Medical |
| Approval Agency | CB, CE, CSA, UL, VDE |
| Efficiency | 85% |
| Features | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input |
| Mfr | ARTESYN / Advanced Energy |
| Minimum Load Required | - |
| Number of Outputs | 2 |
| Packaging | Bulk |
| Part Status | Obsolete |
| Series | MP1 (1200W) |
| Type | Enclosed |
