Key specs
Reverse standoff voltage30 V
Breakdown voltage34.2 V
Clamping voltage49.9 VMax
Peak pulse power150 W
PolarityUnidirectional
| Power | |
|---|---|
| Current - Peak Pulse (10/1000µs) | 3.01A |
| Power Line Protection | No |
| Power - Peak Pulse | 150W |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 34.2V |
| Voltage - Clamping (Max) @ Ipp | 49.9V |
| Voltage - Reverse Standoff (Typ) | 30V |
| AC and DC characteristics | |
| Capacitance @ Frequency | - |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C~175°C(TJ) |
| Package | Bulk |
| Package / Case | A, Axial |
| Supplier Device Package | A, Axial |
| Other | |
| Applications | General Purpose |
| Base Product Number | 1N8164 |
| Mfr | Microchip Technology |
| Product Status | Active |
| Series | - |
| Type | Zener |
