View full reportTechnical parameters
Key specs
Outputs1
| Power | |
|---|---|
| Input Voltage Range (VAC) | 85 ~ 305 |
| Output Voltage (VDC) | 24 |
| Power (W) | 120 |
| Environment and package | |
| Dimensions L x W x H (in) | 4.92 x 3.44 x 1.26 |
| Dimensions L x W x H (mm) | 125 x 87.5 x 32 |
| Mounting Type | DIN Rail |
| Operating Temperature Range (ºC) | -40 ~ +85 |
| Package | Plastic Case |
| RoHS Compliant | Yes |
| Other | |
| Brand | CUI |
| Cooling Type | Convection |
| Market | ITE |
| Number of Outputs | 1 |
| Safety Approvals | CE, UKCA, UL |
| Safety Standards | 61010, 62368 |
