PVT312PBF

SSR RELAY SPST-NO 190MA 0-250V

PVT312PBF is a single-pole, normally open solid-state relay in a 6-pin DIP package, with 0-250V input voltage, 190mA load current, 4000V isolation, and UL certification.Checked against the datasheet

See alternatives Ask AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Input voltage-250 V

Load voltage0 ~ 250 V

Load current190 mAMax

Output typeAC/DC

CircuitSPST-NO

Datasheet-verified parameters

16 items

Parameter	Value and test conditions	Source
Input Voltage	0-250V
Load Current	190mA
Output Type	Single-Pole, Normally-Open
Package	6-pin, molded DIP package, thru-hole
Operating Temperature	-40 to +85 °C
Qualification Level	Industrial (per JEDEC JESD47I guidelines)
RoHS Compliant	Yes
Minimum Control Current	2.0 mA
Maximum Reverse Voltage	6.0 V
Minimum Dielectric Strength, Input-Output	4000 $V_{RMS}$
Minimum Insulation Resistance, Input-Output	$10^{12}$ Ω @ $T_A$ =+25°C, 50%RH, 100 $V_{DC}$
Maximum Capacitance, Input-Output	1.0 pF
Maximum Pin Soldering Temperature	+260 °C (10 seconds maximum)
Storage Temperature	-40 to +100 °C
ESD Tolerance	4000V Human Body Model, 500V Machine Model
Certification	UL recognized and BABT certified

All parameters (15)ExpandCollapse

Power
Load Current	190 mA
Voltage - Input	1.2VDC
Voltage - Load	0 V ~ 250 V
Environment and package
Mounting Type	Through Hole
Package	Tube
Package / Case	6-DIP (0.300", 7.62mm)
Supplier Device Package	6-DIP
Other
Base Product Number	PVT312
Circuit	SPST-NO (1 Form A)
Mfr	Infineon Technologies
On-State Resistance (Max)	10 Ohms
Output Type	AC, DC
Product Status	Active
Series	PVT, HEXFET®
Termination Style	PC Pin
