Yangjie TechnologyChina
Transistors - Bipolar (BJT) - Si
All alternatives
View full reportTechnical parameters
Key specs
TypePNP
Collector-emitter voltage25 V
Collector current500 mAMax
DC current gain11250mA
Power625 mWMax
| Power | |
|---|---|
| Current - Collector Cutoff (Max) | 200nA |
| Current - Collector (Ic) (Max) | 500 mA |
| Power - Max | 625 mW |
| Voltage - Collector Emitter Breakdown (Max) | 25 V |
| AC and DC characteristics | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 112 @ 50mA, 1V |
| Frequency - Transition | 150MHz |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C~150°C(TJ) |
| Package | Tape & Reel (TR) |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Supplier Device Package | TO-92 |
| Other | |
| Mfr | Yangjie Technology |
| Product Status | Active |
| Series | - |
| Transistor Type | PNP |
| Vce Saturation (Max) @ Ib, Ic | 600mV @ 50mA, 500mA |
