View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | SMAF |
| Other | |
| IPP(A) | 35.29 |
| IR@VRWM(μA) | 5 |
| PPk（W） | 600 |
| Status | Active |
| Tj（℃） | -55～+175 |
| Type | Uni |
| VBR _Max(V) | 12.3 |
| VBR _Min(V) | 11.1 |
| VC@IPP(V) | 17 |
| VRWM(V) | 10 |
Documents
DatasheetDatasheet · 355.9 KB · 2026-09-23EnvironmentalEnvironmental · 4.4 MB · 2026-09-23EnvironmentalEnvironmental · 4.4 MB · 2026-09-23EnvironmentalEnvironmental · 1.5 MB · 2026-09-23EnvironmentalEnvironmental · 1.4 MB · 2026-09-23Package DrawingPackage Drawing · 325.8 KB · 2026-09-23
