Key specs
Reverse standoff voltage40 V
Breakdown voltage44.4 V
Clamping voltage64.5 VMax
Peak pulse power400 W
PolarityUnidirectional
| Power | |
|---|---|
| Current - Peak Pulse (10/1000µs) | 6.2A |
| Power Line Protection | No |
| Power - Peak Pulse | 400W |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 44.4V |
| Voltage - Clamping (Max) @ Ipp | 64.5V |
| Voltage - Reverse Standoff (Typ) | 40V |
| AC and DC characteristics | |
| Capacitance @ Frequency | - |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Package | Bulk |
| Package / Case | DO-221AC, SMA Flat Leads |
| Supplier Device Package | DO-221AC (SMA-FL) |
| Other | |
| Applications | General Purpose |
| Base Product Number | SMAF40 |
| Mfr | Micro Commercial Co |
| Product Status | Active |
| Series | - |
| Type | Zener |
