Formosa Microsemi Co., Ltd.Taiwan, China
TVS SMD 75V 1000W Bi-directiona
All alternatives
View full reportTechnical parameters
Key specs
Reverse standoff voltage75 V
Breakdown voltage83.3 V
Clamping voltage121 VMax
Peak pulse power1 kW
PolarityBidirectional
| Power | |
|---|---|
| Bidirectional Channels | 1 |
| Current - Peak Pulse (10/1000µs) | 8.33A |
| Power Line Protection | No |
| Power - Peak Pulse | 1000W (1kW) |
| Voltage - Breakdown (Min) | 83.3V |
| Voltage - Clamping (Max) @ Ipp | 121V |
| Voltage - Reverse Standoff (Typ) | 75V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~150°C |
| Package | Tape & Reel (TR) |
| Package / Case | DO-214AA, SMB |
| Supplier Device Package | SMB-F |
| Other | |
| Mfr | Formosa Microsemi Co., Ltd. |
| Product Status | Active |
| Series | Automotive, AEC-Q101 |
Documents
No documents are linked to this part yet.
