View full reportTechnical parameters
| Power | |
|---|---|
| Ipp最大峰值脉冲电流 | 46.5A |
| Ir最大反向漏电流 | 100μA |
| IR-最大反向漏电流 | 100μA |
| VBR(min)-最小反向击穿电压 | 8.33V |
| VBR最小反向击穿电压 | 8.33V |
| Vc最大钳位电压 | 12.9V |
| VRWM反向峰值电压 | 7.5V |
| VRWM-反向工作峰值电压 | 7.5V |
| Environment and package | |
| 封装类型1 | SMB |
| Other | |
| Ppk最大峰值脉冲功率 | 600W |
| 引脚数量1 | 2 |
