View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | SMC |
| Other | |
| IPP(A) | 2.31 |
| IR@VRWM(μA) | 5 |
| PPPM（W） | 1500 |
| Status | Active |
| Tj（℃） | -55～+150 |
| Type | Uni |
| VBR_Max(V) | 494 |
| VBR_Min(V) | 447 |
| VC@IPP(V) | 648 |
| VRWM(V) | 400 |
