View full reportTechnical parameters
| Power | |
|---|---|
| IR-最大反向漏电流 | 1μA |
| VBR(min)-最小反向击穿电压 | 16.7V |
| Vc最大钳位电压 | 24V |
| VRWM-反向工作峰值电压 | 15V |
| 通道数 | Nch |
| Environment and package | |
| 封装类型1 | SOIC |
| Other | |
| Cj-输入结电容 | 80pF |
| IEC61000-4接触放电 | NKV |
| IEC61000-4空气放电 | NKV |
| Ppk最大峰值脉冲功率 | 500W |
| 引脚数量1 | 8 |
