The SN74LVC7266A contains four independent 2-input XNOR gates. Each gate performs the Boolean function Y = A ⊕ B in positive logic.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Inputs per channel | 2 |
| Number of channels | 4 |
| Environment and package | |
| Operating temperature range (°C) | -40 to 125 |
| Other | |
| Data rate (max) (Mbps) | 100 |
| Features | Over-voltage tolerant inputs, Partial power down (Ioff), Ultra high speed (tpd <5ns) |
| Input type | Standard CMOS |
| IOH (max) (mA) | -24 |
| IOL (max) (mA) | 24 |
| Output type | Push-Pull |
| Rating | Catalog |
| Technology family | LVC |
