MDDGermany
DIODE SCHOTTKY 60V 3A SMAF
All alternatives
View full reportTechnical parameters
Key specs
Reverse voltage60 V
Average rectified current3 A
TypeSchottkyFast Recovery =< 500ns，> 200mA (Io)
| Power | |
|---|---|
| Current - Average Rectified (Io) | 3A |
| Current - Reverse Leakage @ Vr | 500 µA @ 60 V |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature - Junction | -55°C~150°C |
| Package | Tape & Reel (TR) |
| Package / Case | DO-221AC, SMA Flat Leads |
| Supplier Device Package | SMAF |
| Other | |
| Capacitance @ Vr, F | 180pF @ 4V, 1MHz |
| Diode Type | Schottky |
| Mfr | MDD |
| Product Status | Active |
| Series | SMAF |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
Documents
No documents are linked to this part yet.
