STMicroelectronicsSwitzerland
Mainstream Arm Cortex-M0 Value l
All alternatives
View full reportTechnical parameters
Key specs
CoreCORTEX-M0
Core size32 bit
Speed48 MHzMax
Flash64 kB
RAM8 kB
I/O count55
Supply voltage2.4 ~ 3.6 V
| Power | |
|---|---|
| Voltage - Supply (Vcc/Vdd) | 2.4V ~ 3.6V |
| Environment and package | |
| Core Size | 32-Bit Single-Core |
| EEPROM Size | - |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package | Tray |
| Package / Case | 64-LQFP |
| Program Memory Size | 64KB (64K x 8) |
| RAM Size | 8K x 8 |
| Other | |
| Base Product Number | STM32F030 |
| Connectivity | I²C, SPI, UART/USART |
| Core Processor | ARM® Cortex®-M0 |
| Data Converters | A/D 18x12b |
| DigiKey Programmable | Not Verified |
| Mfr | STMicroelectronics |
| Number of I/O | 55 |
| Oscillator Type | Internal |
| Peripherals | DMA, POR, PWM, WDT |
| Product Status | Active |
| Program Memory Type | FLASH |
| Series | STM32F0 |
| Speed | 48MHz |
Documents
No documents are linked to this part yet.
