The TL06x (TL061, TL062, and TL064) family of industry-standard operational amplifiers (op amps) mirror the TL07x and TL08x family of op amps with lower power consumption. These devices provide outstanding value for cost-sensitive applications, featuring high input impedance, wide bandwidth, high slew rate, and low input offset and input bias currents. High ESD (1.5 kV, HBM), integrated EMI and RF filters, and wide temperature operation enable the TL06x devices to be used in rugged and environmentally-demanding applications.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Input bias current (max) (pA) | 200 |
| Input common mode headroom (to negative supply) (typ) (V) | 3 |
| Input common mode headroom (to positive supply) (typ) (V) | 0 |
| Iq per channel (typ) (mA) | 0.2 |
| Number of channels | 2 |
| Output swing headroom (to negative supply) (typ) (V) | 1.5 |
| Output swing headroom (to positive supply) (typ) (V) | -1.5 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 30 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 7 |
| AC and DC characteristics | |
| CMRR (typ) (dB) | 86 |
| Offset drift (typ) (µV/°C) | 10 |
| Slew rate (typ) (V/µs) | 3.5 |
| Vos (offset voltage at 25°C) (max) (mV) | 15 |
| Environment and package | |
| Operating temperature range (°C) | -40 to 85 |
| Other | |
| Architecture | CMOS |
| Features | Standard Amps |
| GBW (typ) (MHz) | 1 |
| Iout (typ) (A) | 0.01 |
| Rail-to-rail | In to V+ |
| Rating | Catalog |
| Vn at 1 kHz (typ) (nV√Hz) | 42 |
