View full reportTechnical parameters
| Power | |
|---|---|
| 输出侧供电电压(Max) | 30V |
| 输出侧供电电压(Min) | 15V |
| 输出拉电流峰值(Source) | 2.5A |
| 输出灌电流峰值(Sink) | 2.5A |
| 集成供电电源 | 0 |
| AC and DC characteristics | |
| 脉宽失真时间(Max) | 350ns |
| 输出关断延迟时间(Max) | 500ns |
| 输出开启延迟时间(Max) | 500ns |
| Environment and package | |
| UL1577隔离电压等级 | 3750Vrms |
| 封装类型1 | DIP |
| Other | |
| 共模瞬态抗扰度 | 15KV/us |
| 引脚数量1 | 8 |
| 死区时间控制 | 0 |
| 米勒钳位保护 | 0 |
| 输出上升时间(Typ) | 15ns |
| 输出下降时间(Typ) | 8ns |
| 饱和故障检测 | 0 |
