PanasonicJapan
RELAY TELECOM DPDT 1A 24VDC
All alternatives
View full reportTechnical parameters
Key specs
Coil voltage24 V
Contact formDPDT
Contact current1 AMax
Switching voltage125 VMax
| Power | |
|---|---|
| Coil Current | 8.3 mA |
| Coil Voltage | 24VDC |
| Contact Rating (Current) | 1 A |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2.4 VDC |
| Switching Voltage | 125VAC, 110VDC - Max |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~70°C |
| Package | Tube |
| Other | |
| Coil Insulation | - |
| Coil Resistance | 2.88 kOhms |
| Coil Type | Non Latching |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver (Ag), Gold (Au) |
| Features | - |
| Mfr | Panasonic Electric Works |
| Operate Time | 3 ms |
| Product Status | Active |
| Relay Type | Telecom |
| Release Time | 3 ms |
| Seal Rating | - |
| Series | TQ |
| Termination Style | PC Pin |
