RELAY TELECOM DPDT 1A 5VDC
All alternatives
View full reportTechnical parameters
Key specs
Coil voltage5 V
Contact formDPDT
Contact current1 AMax
Switching voltage125 VMax
| Power | |
|---|---|
| Coil Current | 28.1 mA |
| Coil Voltage | 5VDC |
| Contact Rating (Current) | 1 A |
| Must Operate Voltage | 3.75 VDC |
| Must Release Voltage | 0.5 VDC |
| Switching Voltage | 125VAC, 110VDC - Max |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~70°C |
| Package | Tube |
| Other | |
| Base Product Number | TQ2-5V |
| Coil Insulation | - |
| Coil Resistance | 178 Ohms |
| Coil Type | Non Latching |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Features | - |
| Mfr | Panasonic Electric Works |
| Operate Time | 3 ms |
| Product Status | Active |
| Relay Type | Telecom |
| Release Time | 3 ms |
| Seal Rating | - |
| Series | TQ |
| Termination Style | PC Pin |
