Cinch Connectivity SolutionsUnited States
CONN BNC PLUG STR 50OHM SOLDER
All alternatives
View full reportTechnical parameters
Key specs
Connector styleBNC
GenderMale
Impedance50 Ω
Max frequency4 GHzMax
| Power | |
|---|---|
| Voltage Rating | 500 V |
| AC and DC characteristics | |
| Frequency - Max | 4 GHz |
| Impedance | 50Ohm |
| Environment and package | |
| Mounting Feature | Bulkhead - Rear Side Nut |
| Mounting Type | Panel Mount |
| Operating Temperature | -55°C~85°C |
| Package | Bulk |
| Other | |
| Base Product Number | VB20 |
| Body Finish | Nickel |
| Body Material | Brass |
| Cable Group | - |
| Center Contact Material | Brass |
| Center Contact Plating | Gold |
| Connector Style | BNC |
| Connector Type | Plug, Male Pin |
| Contact Termination | Solder Cup |
| Dielectric Material | Polyoxymethylene (POM) |
| Fastening Type | Bayonet Lock |
| Features | - |
| Housing Color | Silver |
| Includes | 4 pcs - 1 Connector, 1 Nut, 1 Solder Tag, 1 Washer |
| Ingress Protection | - |
| Insertion Loss | 0.2dB |
| Mating Cycles | 500 |
| Mfr | Cinch Connectivity Solutions |
| Number of Ports | 1 |
| Product Status | Active |
| Series | - |
| Shield Termination | Solder Tag |
