VS-15CTQ045S

Vishay VS-15CTQ045S is a 45V, 2x7.5A common cathode Schottky rectifier in D2PAK (TO-263AB) package, featuring low forward voltage drop and high frequency operation for switching power supplies.Checked against the datasheet

See alternatives Ask AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Reverse voltage45 V

Average rectified current15 A15 A (50 % duty cycle at TC = 123 °C

Forward voltage510 mVMax · TJ = 125 °C

TypeSchottky

Datasheet-verified parameters

14 items

Parameter	Value and test conditions	Source
Maximum DC reverse voltage	45 V
Maximum average forward current	15 A (50 % duty cycle at TC = 123 °C, rectangular waveform)
Forward voltage	0.51 V (7.5 Apk, TJ = 125 °C, per leg)
Diode type	Schottky rectifier, Common cathode
Package	D2PAK (TO-263AB)
Junction temperature range	-55 to +150 °C
Grade	MSL level 1, per J-STD-020
RoHS compliance	RoHS-compliant
Halogen-free	Halogen-free
Maximum peak one cycle non-repetitive surge current	810 A (5 μs sine or 3 μs rect. pulse)
Non-repetitive avalanche energy	10 mJ (TJ = 25 °C, IAS = 1.20 A, L = 11.10 mH)
Maximum reverse current	32 mA (at 125 °C)
Maximum working peak reverse voltage	45 V
Repetitive avalanche current	1.5 A (Current decaying linearly to zero in 1 μs, VA = 1.5 x VR typical)
