WIZnetSouth Korea
IC MCU 32BIT 128KB FLASH 64TQFP
All alternatives
View full reportTechnical parameters
Key specs
CoreCORTEX-M0
Core size32 bit
Speed48 MHzMax
Flash128 kB
RAM16 kB
I/O count34
Supply voltage2.7 ~ 5.5 V
| Power | |
|---|---|
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Environment and package | |
| Core Size | 32-Bit Single-Core |
| EEPROM Size | 6K x 8 |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C~70°C(TA) |
| Package | Tray |
| Package / Case | 64-LQFP |
| Program Memory Size | 128KB (32K x 32) |
| RAM Size | 16K x 8 |
| Supplier Device Package | 64-TQFP (7x7) |
| Other | |
| Base Product Number | W7500 |
| Connectivity | Ethernet/TCP/IP, I²C, SSP, UART/USART |
| Core Processor | ARM® Cortex®-M0 |
| Data Converters | A/D 9x12b |
| Mfr | WIZnet |
| Number of I/O | 34 |
| Oscillator Type | External, Internal |
| Peripherals | DMA, POR, PWM, WDT |
| Product Status | Active |
| Program Memory Type | FLASH |
| Series | - |
| Speed | 48MHz |
Documents
No documents are linked to this part yet.
