242190-3

Производится

MCX Jack to TNC Jack Adapter 50 Ohm Straight Bulkhead

Все аналоги

Характеристики по постоянному и переменному току
Frequency (Max GHz)	6
Impedance (Ohms)	50
Условия эксплуатации и корпус
Mil Qualified	Not Mil Qualified
Panel Mounting Feature	Bulkhead
Temp (Max Degrees Celsius)	85
Temp (Min Degrees Celsius)	-40
Другое
Adapter Configuration	MCX Jack to TNC Jack
Adapter Type	Between-Series
Attributes	Adapter Configuration
Body Finish	Gold
Body Material	Brass
Contact Finish	Gold
Contact Material	Phosphor Bronze
Country of Origin	CN
Details	MCX Jack to TNC Jack
Document Title	242190-3 PDF Customer Drawing (Size: 37.4 KB)
ECCN	EAR99
HTS Code	8536.69.4010
Insulator Material	PTFE
IP Rating	Not Rated
Isolated	No
Low PIM	No
Non Magnetic	Contains Magnetic Materials
Orientation	Straight
PFAS	Contains PFAS
Publish Date	5/7/2026
Type	pdf
